| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LVC1G04DBVTE4
IC INVERTER 1CH 1-INP SOT23-5
|
74LVC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.58V ~ 1.65V | 1.07V ~ 3.85V |
|
8403901DA
MILITARY 2-CH, 4-INPUT, 2-V TO 6
|
54HC | Tube | Active | NAND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
5962-8683301DA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54ALS | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74LVC08APWRG3
IC GATE AND 4CH 2-INP 14TSSOP
|
74LVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
SNJ54HCT14FK
IC INVERT SCHMITT 6CH 6IN 20LCCC
|
54HCT | Tube | Active | Inverter | 6 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 1.2V ~ 1.4V | 1.9V ~ 2.1V |
|
SN74AHC08MPWREP
IC GATE AND 4CH 2-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
84046012A
MILITARY 4-CH, 2-INPUT, 2-V TO 6
|
54HC | Tube | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LVC04APWE4
IC INVERTER 6CH 1-INP 14TSSOP
|
74LVC | Tube | Discontinued at | Inverter | 1 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
CD74HCU04EG4
IC INVERTER 6CH 1-INP 14DIP
|
74HCU | Tube | Discontinued at | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.1V | 1.7V ~ 4.8V |
|
SN74AHC08DGVR
IC GATE AND 4CH 2-INP 14TVSOP
|
74AHC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
5962-8984502VDA
SPACE 4-CH, 4-INPUT, 2-V TO 6-V
|
54HC | Tube | Active | NAND Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 1V ~ 3.2V | 1.5V ~ 4.2V |
|
|
SN74AHCT132PWR-P
PROTOTYPE
|
74AHCT | Bulk | Active | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | - | 1.9V ~ 2.1V |
