| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LV08APW
IC GATE AND 4CH 2-INP 14TSSOP
|
74LV | Tube | Discontinued at | AND Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
SN74LVU04AD
IC INVERTER 6CH 1-INP 14SOIC
|
74LVU | Bulk | Active | Inverter | 1 | - | 2V ~ 5.5V | 12mA, 12mA | 0.3V | 1.7V |
|
SN74LS10NSR
IC GATE NAND 3CH 3-INP 14SOP
|
74LS | Tape & Reel (TR) | Active | NAND Gate | 3 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN7406DE4
IC INVERTER OPEN 6CH 1-IN 14SOIC
|
7400 | Tube | Discontinued at | Inverter | 1 | Open Collector | 4.75V ~ 5.25V | -, 40mA | 0.8V | 2V |
|
SN74LV21APW
IC GATE AND 2CH 4-INP 14TSSOP
|
74LV | Tube | Discontinued at | AND Gate | 4 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
SN74LV06APW
IC INVERTER OD 6CH 1-INP 14TSSOP
|
74LV | Tube | Discontinued at | Inverter | 1 | Open Drain | 2V ~ 5.5V | -, 16mA | 0.5V | 1.5V |
|
SN7404D
IC INVERTER 6CH 1-INP 14SOIC
|
7400 | Tube | Active | Inverter | 1 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
CD74HC11E-NG
IC GATE AND 3CH 3-INP 14DIP
|
74HC | Tube | Active | AND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC86NE4
IC GATE XOR 4CH 2-INP 14DIP
|
74HC | Tube | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LV08APWRE4
IC GATE AND 4CH 2-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
SN74LS30NE4
SINGLE 8-INPUT, 4.75-V TO 5.25-V
|
74LS | Tube | Active | NAND Gate | 8 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74LVCU04DBLE
INVERTER
|
74LVCU | Bulk | Active | - | - | - | - | - | - | - |
