| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
LM9061MX
IC GATE DRVR HIGH-SIDE 8SOIC
|
- | Tape & Reel (TR) | Obsolete | High-Side | Single | 1 | N-Channel MOSFET | 7V ~ 26V | 1.5V, 3.5V | - |
|
SN55451BJG
IC GATE DRVR LOW-SIDE 8CDIP
|
- | Tube | Active | Low-Side | Independent | 2 | - | 4.5V ~ 5.5V | 0.8V, 2V | 500mA, 500mA |
|
|
LM5101BMA
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tube | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 2A, 2A |
|
5962-9579801M2A
1.5-A/1.5-A SINGLE-CHANNEL GATE
|
- | Tube | Active | Low-Side | Single | 1 | N-Channel, P-Channel MOSFET | 5V ~ 40V | 0.8V, 2.4V | 1.5A, 1.5A |
|
|
LM2726M
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tube | Obsolete | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 4V ~ 7V | 0.25V, 2.4V | 3A, 3.2A |
|
|
DRV8304HLRHAR
PROTOTYPE
|
- | Bulk | Active | High-Side or Low-Side | Single | 3 | N-Channel MOSFET | 6V ~ 38V | 0.8V, 1.5V | 150mA, 300mA |
|
|
LM2726MX/NOPB
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 4V ~ 7V | 0.25V, 2.4V | 3A, 3.2A |
|
|
UCC37324DG4
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tube | Discontinued at | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 15V | 1V, 2V | 4A, 4A |
|
LM5106MMX
IC GATE DRVR HALF-BRIDGE 10VSSOP
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Synchronous | 2 | N-Channel MOSFET | 8V ~ 14V | 0.8V, 2.2V | 1.2A, 1.8A |
|
|
5962-0051401VEA
RADIATION-TOLERANT QMLV, 3-A/3-A
|
- | Tube | Active | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 5V ~ 35V | 0.8V, 2V | 3A, 3A |
|
LM5100BSDX
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 2A, 2A |
|
|
LM5100MX
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 3V, 8V | 1.6A, 1.6A |
