| Image | Mfr Part # | Series | Package | Product Status | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
UCC27301ADR
120V 4A HALF-BRIDGE DRIVER WITH
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 8V ~ 17V | 1.9V, 1.7V | 3.7A, 4.5A |
|
UC3705J
MILITARY-GRADE 1.5-A/1.5-A DUAL-
|
- | Tube | Active | Low-Side | Single | 1 | N-Channel MOSFET | 5V ~ 40V | 0.8V, 2.4V | 2.5A, 2.5A |
|
LM5109BMA
IC GATE DRVR HALF-BRIDGE 8SOIC
|
- | Bulk | Not For New Designs | Half-Bridge | Independent | 2 | N-Channel MOSFET | 8V ~ 14V | 0.8V, 2.2V | 1A, 1A |
|
UCC27212DPRR
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Active | Half-Bridge | Independent | 2 | N-Channel MOSFET | 7V ~ 17V | 1.6V, 2.3V | 4A, 4A |
|
|
LM5110-1SD
IC GATE DRVR LOW-SIDE 10WSON
|
- | Tape & Reel (TR) | Not For New Designs | Low-Side | Independent | 2 | N-Channel MOSFET | 3.5V ~ 14V | 0.8V, 2.2V | 3A, 5A |
|
|
UC3705DTR
IC GATE DRVR LOW-SIDE 8SOIC
|
- | Tape & Reel (TR) | Active | Low-Side | Single | 1 | N-Channel MOSFET | 5V ~ 40V | 0.8V, 2.2V | 1.5A, 1.5A |
|
TPS2813PW
IC GATE DRVR LOW-SIDE 8TSSOP
|
- | Tube | Obsolete | Low-Side | Synchronous | 2 | N-Channel, P-Channel MOSFET | 4V ~ 14V | 1V, 4V | 2A, 2A |
|
LM5100CSD
IC GATE DRVR HALF-BRIDGE 10WSON
|
- | Tape & Reel (TR) | Obsolete | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 1A, 1A |
|
LMD18400N/NOPB
IC GATE DRVR HIGH-SIDE 20DIP
|
- | Tube | Obsolete | High-Side | Independent | 4 | N-Channel MOSFET | 7V ~ 28V | 0.8V, 2V | 3A, 3A |
|
TPS2811PW
IC GATE DRVR LOW-SIDE 8TSSOP
|
- | Bulk | Active | Low-Side | Synchronous | 2 | N-Channel, P-Channel MOSFET | 4V ~ 14V | 1V, 4V | 2A, 2A |
|
UC3715DP
IC GATE DRVR LOW-SIDE 16SOIC
|
- | Tube | Obsolete | Low-Side | Synchronous | 2 | N-Channel, P-Channel MOSFET | 7V ~ 20V | 0.8V, 2V | 500mA, 1A |
|
UC3708DWG4
IC GATE DRVR LOW-SIDE 16SOIC
|
- | Tube | Discontinued at | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 5V ~ 35V | 0.8V, 2V | 3A, 3A |
