| Image | Mfr Part # | Series | Package | Product Status | Function | Delay to 1st Tap | Available Total Delays | Number of Independent Delays | Voltage - Supply | Mounting Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS1000S-35
DS1000 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 7ns | 35ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100LZ-20/TR/C01
IC DELAY LINE 5TAP 20NS 8-SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 4ns | 20ns | 1 | 3V ~ 3.6V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1013-20
IC DELAY LINE 20NS 14DIP
|
- | Tube | Obsolete | Multiple, NonProgrammable | 20ns | 20ns | 3 | 4.75V ~ 5.25V | Through Hole | 14-DIP (0.300", 7.62mm) |
|
DS1000K-50
DS1000 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 10ns | 50ns | 1 | 4.75V ~ 5.25V | Through Hole | 14-DIP (0.300", 7.62mm) |
|
DS1000C-703/T&R
IC DELAY LINE 5TAP 8-SOIC
|
- | Bulk | Obsolete | Tapped | - | - | - | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1135LU-30
IC DELAY LINE 30NS 8UMAX
|
- | Tube | Obsolete | Multiple, NonProgrammable | 30ns | 30ns | 3 | 2.7V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1020S-50
IC DEL LN 256TAP 137.5NS 16SOIC
|
- | Tube | Obsolete | Programmable | 10ns | 137.5ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100Z-30+
IC DELAY LINE 5TAP 30NS 8SOIC
|
- | Tube | Active | Nonprogrammable | 6ns | 30ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1013M-200
IC DELAY LINE 200NS 8DIP
|
- | Tube | Obsolete | Multiple, NonProgrammable | 200ns | 200ns | 3 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
|
DS1023S-50
IC DEL LN 256TAP 127.5NS 16SOIC
|
- | Tube | Obsolete | 1-Shot, Programmable | 16.5ns | 127.5ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1005-125
DS1005 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 25ns | 125ns | 1 | 4.75V ~ 5.25V | Through Hole | 14-DIP (0.300", 7.62mm) |
|
DS1100M-40
IC DELAY LINE 5TAP 40NS 8DIP
|
- | Tube | Obsolete | Nonprogrammable | 8ns | 40ns | 1 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
