| Image | Mfr Part # | Series | Package | Product Status | Function | Delay to 1st Tap | Available Total Delays | Number of Independent Delays | Voltage - Supply | Mounting Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS1013-75+
IC DELAY LINE 75NS 14DIP
|
- | Tube | Obsolete | Multiple, NonProgrammable | 75ns | 75ns | 3 | 4.75V ~ 5.25V | Through Hole | 14-DIP (0.300", 7.62mm) |
|
DS1005S-100/T&R
IC DELAY LINE 5TAP 100NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 20ns | 100ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100LU-200
DELAY LINE 3V 5TAP 200NS 8-USOP
|
* | Tube | Discontinued at | Tapped | 40ns | 200ns | - | 3.3V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1035Z-30/T&R
DELAY LINE 35TAP 30NS 8-SOIC
|
- | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - |
|
DS1100Z-35+T
IC DELAY LINE 5TAP 35NS 8SOIC
|
- | Tape & Reel (TR) | Active | Nonprogrammable | 7ns | 35ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1013S-12/T&R
IC DELAY LINE 12NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | Multiple, NonProgrammable | 12ns | 12ns | 3 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1013M-30+
IC DELAY LINE 30NS 8DIP
|
- | Tube | Obsolete | Multiple, NonProgrammable | 30ns | 30ns | 3 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
|
DS1100U-125+
IC DELAY LINE 5TAP 125NS 8UMAX
|
- | Tube | Active | Nonprogrammable | 25ns | 125ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1007-7
DS1007 7-IN-1 SILICON DELAY LINE
|
- | Bulk | Active | Multiple, NonProgrammable | 7ns | 3ns ~ 10ns, 9ns ~ 40ns | 7 | 4.75V ~ 5.25V | Through Hole | 16-DIP (0.300", 7.62mm) |
|
DS1135Z-10/TR
3V 3-IN-1 HIGH-SPEEDDELAY LINE
|
- | Bulk | Active | Multiple, NonProgrammable | 10ns | 10ns | 3 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1013S-80/T&R
IC DELAY LINE 80NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | Multiple, NonProgrammable | 80ns | 80ns | 3 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
|
DS1100Z-40+T
IC DELAY LINE 5TAP 40NS 8SOIC
|
- | Tape & Reel (TR) | Active | Nonprogrammable | 8ns | 40ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
