| Image | Mfr Part # | Series | Package | Product Status | Function | Delay to 1st Tap | Available Total Delays | Number of Independent Delays | Voltage - Supply | Mounting Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS1100Z-150
IC DELAY LINE 5TAP 150NS 8SOIC
|
- | Tube | Obsolete | Nonprogrammable | 30ns | 150ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1135Z-25
IC DELAY LINE 25NS 8SOIC
|
- | Tube | Discontinued at | Multiple, NonProgrammable | 25ns | 25ns | 3 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1004Z-4/T&R
IC DELAY LINE 5TAP 21NS 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 5ns | 21ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1013M-10
IC DELAY LINE 10NS 8DIP
|
- | Tube | Obsolete | Multiple, NonProgrammable | 10ns | 10ns | 3 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
|
DS1010-400
DELAY LINE 10TAP 400NS MAX 14DIP
|
* | Tube | Obsolete | Tapped | 40ns | 400ns | - | 5V | Through Hole | 14-DIP (0.300", 7.62mm) |
|
DS1100LZ-75/T&R
IC DELAY LINE 5TAP 75NS 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 15ns | 75ns | 1 | 3V ~ 3.6V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1023S-25/T&R
IC DEL LN 256TAP 63.75NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | 1-Shot, Programmable | 16.5ns | 63.75ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100Z-60
IC DELAY LINE 5TAP 60NS 8SOIC
|
- | Tube | Obsolete | Nonprogrammable | 12ns | 60ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1110S-50
IC DELAY LINE 10TAP 50NS 16SOIC
|
- | Tube | Obsolete | Nonprogrammable | 5ns | 50ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100LU-20
IC DELAY LINE 5TAP 20NS 8UMAX
|
- | Tube | Discontinued at | Nonprogrammable | 4ns | 20ns | 1 | 3V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1135Z-12+
IC DELAY LINE 12NS 8SOIC
|
- | Bulk | Obsolete | Multiple, NonProgrammable | 12ns | 12ns | 3 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1100LU-300/T&R
IC DELAY LINE 5TAP 300NS 8UMAX
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 60ns | 300ns | 1 | 3V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
