| Image | Mfr Part # | Series | Package | Product Status | Type | Circuit | Current - Output High, Low | Voltage Supply Source | Voltage - Supply | Operating Temperature | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
PCA8550PWR
IC MULTIPLEXER 1 X 4:4 16TSSOP
|
- | Tape & Reel (TR) | Obsolete | Multiplexer | 1 x 4:4 | - | Single Supply | 3V ~ 3.6V | 0°C ~ 70°C | Surface Mount |
|
74CB3T16211DGGRE4
IC BUS SWITCH 12 X 1:1 56TSSOP
|
74CB | Tape & Reel (TR) | Discontinued at | Bus Switch | 12 x 1:1 | - | Single Supply | 2.3V ~ 3.6V | -40°C ~ 85°C | Surface Mount |
|
SN74LS258D
MULTIPLEXER, LS SERIES TTL
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
5962-9856401QEA
BCD-TO-SEVEN-SEGMENT DECODERS/DR
|
- | Tube | Active | Decoder | 1 x 4:7 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
SNJ54S257W
IC MULTIPLEXER 4 X 2:1 16CFP
|
- | Tube | Active | Data Selector/Multiplexer | 4 x 2:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
SN74CB3Q32245GKER
IC BUS SWITCH 8 X 1:1 96LFBGA
|
74CB | Tape & Reel (TR) | Obsolete | Bus Switch | 8 x 1:1 | - | Single Supply | 2.3V ~ 3.6V | -40°C ~ 85°C | Surface Mount |
|
|
TS5N118PWR
IC MUX/DEMUX 1 X 8:1 16TSSOP
|
- | Tape & Reel (TR) | Obsolete | Multiplexer/Demultiplexer | 1 x 8:1 | - | Single Supply | 4.75V ~ 5.25V | -40°C ~ 85°C | Surface Mount |
|
SN74CBT3384DWR
BUS DRIVER
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
54LS670LMQB
STANDARD SRAM, 4X4, 45NS, TTL
|
54LS | Bulk | Active | Register File | 1 x 1:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C (TA) | Surface Mount |
|
SN74LVC138AD
IC DECODER/DEMUX 1X3:8 16SOIC
|
74LVC | Tube | Active | Decoder/Demultiplexer | 1 x 3:8 | - | Single Supply | 1.65V ~ 3.6V | -40°C ~ 85°C | Surface Mount |
|
SN74ABT32318PN
BUS EXCHANGER
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
JM38510/30902BEA
DUAL 4-LINE TO 1-LINE DATA SELEC
|
54LS | Tube | Active | Data Selector/Multiplexer | 2 x 4:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
