| Image | Mfr Part # | Series | Package | Product Status | Type | Circuit | Current - Output High, Low | Voltage Supply Source | Voltage - Supply | Operating Temperature | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LS258BNSRG4
IC MULTIPLEXER 4 X 2:1 16SO
|
74LS | Tape & Reel (TR) | Obsolete | Multiplexer | 4 x 2:1 | - | Single Supply | 4.75V ~ 5.25V | 0°C ~ 70°C | Surface Mount |
|
74S139DC
DECODER/DRIVER, TTL
|
74S | Bulk | Active | Decoder/Demultiplexer | 1 x 2:4 | - | Single Supply | 4.75V ~ 5.25V | 0°C ~ 70°C | Through Hole |
|
CD4514BM
IC DECODER/DEMUX 1X4:16 24SOIC
|
4000B | Tube | Discontinued at | Decoder/Demultiplexer | 1 x 4:16 | - | Dual Supply | 3V ~ 18V | -55°C ~ 125°C | Surface Mount |
|
8413501EA
1-OF-8 DATA SELECTORS/MULTIPLEXE
|
54ALS | Tube | Active | Data Selector/Multiplexer | 1 x 8:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
|
M38510/30908BFA
DUAL 4-LINE TO 1-LINE DATA SELEC
|
54LS | Tube | Active | Data Selector/Multiplexer | 2 x 4:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
CD4512BEE4
CD4512B CMOS 8-CHANNEL DATA SELE
|
4000B | Bulk | Active | Data Selector/Multiplexer | 1 x 8:1 | - | Dual Supply | 3V ~ 18V | -55°C ~ 125°C | Through Hole |
|
SN74HCT139PWR
IC DECODER/DEMUX 1X2:4 16TSSOP
|
74HCT | Tape & Reel (TR) | Active | Decoder/Demultiplexer | 1 x 2:4 | - | Single Supply | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
|
SNJ54ALS138AJ
3-LINE TO 8-LINE DECODERS/DEMULT
|
54ALS | Tube | Active | Decoder/Demultiplexer | 1 x 3:8 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
SNJ54LS151J
IC DATA SEL/MULTPL 1X8:1 16CDIP
|
54LS | Bulk | Active | Data Selector/Multiplexer | 1 x 8:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C (TA) | Through Hole |
|
|
7703201JA
CMOS 4-BIT LATCH/4-TO-16 LINE DE
|
4000B | Tube | Active | Decoder/Demultiplexer | 1 x 4:16 | - | Dual Supply | 3V ~ 18V | -55°C ~ 125°C | Through Hole |
|
54LS153LMQB
MULTIPLEXER, LS SERIES
|
54LS | Bulk | Active | Data Selector/Multiplexer | 2 x 4:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
|
7704701EA
CMOS DUAL BINARY TO 1-OF-4 DECOD
|
4000B | Tube | Active | Decoder/Demultiplexer | 1 x 2:4 | - | Dual Supply | 3V ~ 18V | -55°C ~ 125°C | Through Hole |
