| Image | Mfr Part # | Series | Package | Product Status | Type | Circuit | Current - Output High, Low | Voltage Supply Source | Voltage - Supply | Operating Temperature | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
54LS670DMQB
STANDARD SRAM, 4X4, 45NS, TTL
|
54LS | Bulk | Active | Register File | 1 x 1:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C (TA) | Through Hole |
|
CD74HC151E
IC MULTIPLEXER 1 X 8:1 16DIP
|
74HC | Tube | Active | Multiplexer | 1 x 8:1 | - | Single Supply | 2V ~ 6V | -55°C ~ 125°C | Through Hole |
|
SN54LS258BJ
QUADRUPLE 2-LINE TO 1-LINE DATA
|
54LS | Tube | Active | Data Selector/Multiplexer | 4 x 2:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
|
M38510/33701B2A
3-LINE TO 8-LINE DECODERS/DEMULT
|
54F | Tube | Active | Decoder/Demultiplexer | 1 x 3:8 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Surface Mount |
|
SN74HC157DR
IC MULTIPLEXER 4 X 2:1 16SOIC
|
74HC | Tape & Reel (TR) | Active | Multiplexer | 4 x 2:1 | - | Single Supply | 2V ~ 6V | -40°C ~ 85°C | Surface Mount |
|
SN74LS670DRE4
IC REGISTER FILE 1 X 1:1 16SOIC
|
74LS | Tape & Reel (TR) | Obsolete | Register File | 1 x 1:1 | - | Single Supply | 4.75V ~ 5.25V | 0°C ~ 70°C (TA) | Surface Mount |
|
|
SNJ54LS47J
BCD-TO-SEVEN-SEGMENT DECODERS/DR
|
54LS | Tube | Active | Decoder | 1 x 4:7 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
|
SN74HC42DR
IC DECODER 1 X 4:10 16SOIC
|
74HC | Tape & Reel (TR) | Active | Decoder | 1 x 4:10 | - | Single Supply | 2V ~ 6V | -40°C ~ 85°C | Surface Mount |
|
SN74HC148DT
IC PRIORITY ENCOD 1 X 8:3 16SOIC
|
74HC | Tape & Reel (TR) | Discontinued at | Priority Encoder | 1 x 8:3 | - | Single Supply | 2V ~ 6V | -40°C ~ 85°C | Surface Mount |
|
54LS157DMQB
MULTIPLEXER, LS SERIES
|
54LS | Bulk | Active | Data Selector/Multiplexer | 4 x 2:1 | - | Single Supply | 4.5V ~ 5.5V | -55°C ~ 125°C | Through Hole |
|
SN74HC157N
IC MULTIPLEXER 4 X 2:1 16DIP
|
74HC | Tube | Active | Multiplexer | 4 x 2:1 | - | Single Supply | 2V ~ 6V | -40°C ~ 85°C | Through Hole |
|
|
MM74HC4514J
DECODER/DRIVER, HC/UH SERIES,
|
74HC | Bulk | Active | Decoder/Demultiplexer | 1 x 4:16 | - | Dual Supply | 2V ~ 6V | -40°C ~ 85°C | - |
