| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AUP1G06DCKR
IC INVERTER OD 1CH 1-INP SC70-5
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | Open Drain | 0.8V ~ 3.6V | -, 4mA | 0.1V ~ 0.45V | 3.6V |
|
MM54HC03E/883
NAND GATE, CMOS, CQCC20
|
54HC | Bulk | Active | NAND Gate | 2 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SNJ54HC08FK
MILITARY 4-CH, 2-INPUT, 2-V TO 6
|
54HC | Tube | Active | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
SN74AUP1G00DCKR
IC GATE NAND 1CH 2-INP SC70-5
|
74AUP | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
CD4082BE
IC GATE AND 2CH 4-INP 14DIP
|
4000B | Tube | Active | AND Gate | 4 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74HC05PWRG4
IC INVERTER OD 6CH 1-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
MM54HC11J
AND GATE, HC/UH SERIES, 3-INPUT
|
54HC | Bulk | Active | AND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74HC7032NSRE4
IC GATE OR SCHMITT 4CH 2IN 14SOP
|
74HC | Tape & Reel (TR) | Obsolete | OR Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
SN74AUP1G04DRY2
IC INVERTER 1CH 1-INP 6SON
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
|
CD4093BPW
IC GATE NAND 4CH 2-INP 14TSSOP
|
4000B | Tube | Discontinued at | NAND Gate | 2 | Schmitt Trigger | 3V ~ 18V | 3.4mA, 3.4mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
SN74HC7001DG4
IC GATE AND 4CH 2IN 14SOIC
|
74HC | Tube | Discontinued at | AND Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
CD4030BNSR
IC GATE XOR 4CH 2-INP 14SOP
|
4000B | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
