| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54AHC00W
MILITARY 4-CH, 2-INPUT, 2-V TO 5
|
54AHC | Tube | Active | NAND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AC14PW
IC INVERTER 6CH 1-INP 14TSSOP
|
74AC | Tube | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 24mA, 24mA | 0.5V ~ 1.1V | 2.2V ~ 3.9V |
|
|
JM38510/17002BCA
MILITARY 2-CH, 4-INPUT, 3-V TO 1
|
4000B | Tube | Active | AND Gate | 4 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
CAHCT1G32QDBVRQ1
IC GATE OR 1CH 2-INP SOT23-5
|
Automotive, AEC-Q100, 74AHCT | Tape & Reel (TR) | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
SNJ54HC20FK
MILITARY 2-CH, 4-INPUT, 2-V TO 6
|
54HC | Tube | Active | NAND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74AC04MDREP
IC INVERTER 6CH 1-INP 14SOIC
|
74AC | Tape & Reel (TR) | Active | Inverter | 1 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
CD4082BME4
IC GATE AND 2CH 4-INP 14-SOIC
|
4000B | Tube | Active | AND Gate | 4 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
|
M38510/65203BDA
IC GATE AND 4CH 2-INP 14CFP
|
54HC | Tube | Active | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74AHCT32QPWRQ1
IC GATE OR 4CH 2-INP 14TSSOP
|
Automotive, AEC-Q100, 74AHCT | Tape & Reel (TR) | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
CD4001BM96
IC GATE NOR 4CH 2-INP 14SOIC
|
4000B | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
CD4011BMT
IC GATE NAND 4CH 2-INP 14SOIC
|
4000B | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
MM74HC11J
AND GATE, HC/UH SERIES, 3-INPUT
|
74HC | Bulk | Active | AND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
