| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
4081BDM
IC GATE AND 14CDIP
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
JM54AC08SCA-RH
54AC08 - QUAD 2-INPUT AND GATE -
|
54AC | Bulk | Active | AND Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
74S40DC
DUAL 4 INPUT NAND GATE
|
74S | Bulk | Active | NAND Gate | 4 | - | 4.75V ~ 5.25V | 3mA, 60mA | 0.8V | 2V |
|
|
7426PC
IC GATE NAND 4CH 2-INP 14DIP
|
- | Bulk | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | 1mA, - | - | - |
|
|
7420PCQR
IC GATE NAND 14DIP
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
74S03PC
NAND GATE, TTL, PDIP14
|
74S | Bulk | Obsolete | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | - | - | - |
|
9014DM
IC GATE XOR 4CH 2-INP 16CDIP
|
- | Bulk | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | -, 17.6mA | 0.9V | 1.7V |
|
|
JM54AC86BDA-RH
54AC86 - QUAD 2-INPUT EXCLUSIVE-
|
54AC | Bulk | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
CD4023BMT
IC NAND TRPL 3-INP
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
JM54AC14SDA-LH
54AC14 - HEX INVERTER SCHMITT TR
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
5486FMQB
IC GATE XOR 4CH 2-INP 14CFP
|
- | Bulk | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 800µA, 16mA | 0.8V | 2V |
|
|
4011BDC
IC GATE NAND 4CH 2-INP 14CDIP
|
4011B | Bulk | Active | NAND Gate | 2 | - | - | - | - | - |
