| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
54S40DM
NAND GATE, TTL
|
54S | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 60mA | 0.8V | 2V |
|
54H30DM
IC GATE NAND 1CH 8-INP 14CERDIP
|
54H | Bulk | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | - | - | - |
|
|
949DM
IC GATE NAND
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
4019BDC
IC GATE OR
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
JD54F00SDA
IC GATE NAND 4CH 2-INP 14CFP
|
54F | Bulk | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
9016DC
IC GATE NAND 2CH 4-INP 14CDIP
|
- | Bulk | Active | NAND Gate | 4 | - | 4.75V ~ 5.25V | 1.2mA, 16mA | 0.85V | 1.8V |
|
|
JD9946BDA
IC
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
9504DC
IC GATE NOR
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
JD54LS27BDA
IC GATE NOR TRPL 3-INP
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
5422DM
IC GATE NAND 2CH 4-INP 14CDIP
|
- | Bulk | Active | NAND Gate | 4 | Open Collector | 4.5V ~ 5.5V | 250µA, 16mA | 0.8V | 2V |
|
|
54ACTQ04J-QMLV
IC INVERTER 6CH 1-INP 14CERDIP
|
54ACTQ | Bulk | Active | Inverter | 1 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
54H40FM
IC GATE NAND 2CH 4-INP 14CFP
|
54H | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | - | - | - |
