| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
54H08DM
IC GATE AND 4CH 2-INP 14CERDIP
|
54H | Bulk | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | - | - | - |
|
JD54LS00B2A
IC GATE NAND
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
54H10DM
IC GATE NAND 3CH 3-INP 14CERDIP
|
- | Bulk | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | - | - | - |
|
|
5486DMQB
IC GATE XOR 4CH 2-INP 14CERDIP
|
- | Bulk | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 800µA, 16mA | 0.8V | 2V |
|
54ALS27E/883
IC GATE NOR
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
74LS30PC
NAND GATE, TTL, PDIP14
|
74LS | Bulk | Active | NAND Gate | 8 | - | 4.75V ~ 5.25V | - | - | - |
|
|
932PC
IC GATE NAND
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
7439PC
IC GATE NAND 4CH 2-INP 14DIP
|
- | Bulk | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | 250µA, 80mA | - | 2V |
|
9386FM
IC GATE XNOR
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
54S133DM
NAND GATE
|
54S | Bulk | Active | NAND Gate | 13 | - | 4.5V ~ 5.5V | - | - | - |
|
DM54LS08J/883
AND GATE, LS SERIES
|
54LS | Bulk | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
74S140PC
NAND GATE
|
74S | Bulk | Active | NAND Gate | 4 | - | 4.75V ~ 5.25V | -, 60mA | - | - |
