| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54F30W
MILITARY SINGLE 8-INPUT, 4.5-V T
|
54F | Tube | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74AHCT132N
IC GATE NAND 4CH 2IN 14DIP
|
74AHCT | Tube | Active | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
SN74S08NSRE4
IC GATE AND 4CH 2-INP 14SOP
|
74S | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SN74S00DR
IC GATE NAND 4CH 2-INP 14SOIC
|
74S | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SN74AHCT14DBR
IC INV SCHMITT 6CH 1-IN 14SSOP
|
74AHCT | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
SN74HC04DRG4
IC INVERTER 6CH 1-INP 14SOIC
|
74HC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LV1T02DBVR
IC GATE NOR 1CH 2-INP SOT23-5
|
74LV | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 1.6V ~ 5.5V | 8mA, 8mA | 0.58V ~ 0.8V | 0.94V ~ 2.1V |
|
|
M38510/33002B2A
MILITARY 6-CH, 4.5-V TO 5.5-V BI
|
54F | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HC14PW
IC INVERTER 6CH 1-INP 14TSSOP
|
74HC | Bulk | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
SN74AHCT32PWG4
IC GATE OR 4CH 2-INP 14TSSOP
|
74AHCT | Bulk | Discontinued at | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
SN74S09DRG4
IC GATE AND OPEN 4CH 2-IN 14SOIC
|
74S | Tape & Reel (TR) | Obsolete | AND Gate | 2 | Open Collector | 4.75V ~ 5.25V | -, 20mA | 0.8V | 2V |
|
|
SN74LV20ADBR
IC GATE NAND 2CH 4-INP 14SSOP
|
74LV | Tape & Reel (TR) | Active | NAND Gate | 4 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
