| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AHC86PWR
IC GATE XOR 4CH 2-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHCT1G02DCKR
IC GATE NOR 1CH 2-INP SC70-5
|
74AHCT | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74AHC1G08DCKRG4
IC GATE AND 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC05D
IC INVERTER OD 6CH 1-INP 14SOIC
|
74AHC | Tube | Active | Inverter | 1 | Open Drain | 2V ~ 5.5V | -, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AUP3G06RSER
IC INVERTER OD 3CH 3-INP 8UQFN
|
74AUP | Tape & Reel (TR) | Active | Inverter | 3 | Open Drain | 0.8V ~ 3.6V | -, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
SN74AHC1G86DCKT
IC GATE XOR 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Discontinued at | XOR (Exclusive OR) | 2 | Schmitt Trigger Input | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
SN74AUP3G14RSER
IC INVERT SCHMITT 3CH 3-IN 8UQFN
|
74AUP | Tape & Reel (TR) | Active | Inverter | 3 | Schmitt Trigger | 0.8V ~ 3.6V | 4mA, 4mA | 0.1V ~ 0.88V | 0.6V ~ 2.29V |
|
SN74AHCT86RGYR
IC GATE XOR 4CH 2-INP 14VQFN
|
74AHCT | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74AHC1G14DCK3
IC INVERT SCHMITT 1CH 1IN SC70
|
74AHC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
CAHCT1G32IDBVRCT
OR GATE, AHCT/VHCT SERIES
|
74AHCT | Bulk | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
SN74LV21APW-P
PROTOTYPE
|
74LV | Bulk | Active | AND Gate | 4 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
|
SN74LV10APWRG4
IC GATE NAND 3CH 3-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Discontinued at | NAND Gate | 3 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
