| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AHCT1G14DCKT
IC INVERT SCHMITT 1CH 1IN SC70
|
74AHCT | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 2V |
|
SN74LV1T08DCKRG4
IC GATE AND 1CH 2-INP SC70-5
|
74LV | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 1.6V ~ 5.5V | 8mA, 8mA | 0.58V ~ 0.8V | 0.94V ~ 2.1V |
|
SN74AHC05N
IC INVERTER OD 6CH 1-INP 14DIP
|
74AHC | Tube | Active | Inverter | 1 | Open Drain | 2V ~ 5.5V | -, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AUP2G06DCKR
IC INVERTER OD 2CH 2-INP SC70-6
|
74AUP | Tape & Reel (TR) | Active | Inverter | 2 | Open Drain | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
SN74AHC14DR
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74AHC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74AUP1G00DBVR
IC GATE NAND 1CH 2-INP SOT23-5
|
74AUP | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 0.8V ~ 3.6V | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V |
|
SN74AHC1G14DCKRG4
IC INVERT SCHMITT 1CH 1IN SC70
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
SN74LV08APWRG3
IC GATE AND 4CH 2-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
SN74AHC04BQAR
IC INVERTER 6CH 6-INP 14WQFN
|
74AHC | Tape & Reel (TR) | Active | Inverter | 6 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74LV1T00DBVRG4
IC GATE NAND 1CH 2-INP SOT23-5
|
74LV | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 1.6V ~ 5.5V | 8mA, 8mA | 0.58V ~ 0.8V | 0.94V ~ 2.1V |
|
|
V62/03605-01YE
IC INVERTER 6CH 6-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Active | Inverter | 6 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 1.9V ~ 3.35V | 2.2V ~ 3.85V |
|
SN74AHC1G04DRLR
IC INVERTER 1CH 1-INP SOT5
|
74AHC | Tape & Reel (TR) | Active | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
