| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LVC1G32QDBVRQ1
IC GATE OR 1CH 2-INP SOT23-5
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | OR Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN7405NG4
IC INV OPEN COL 6CH 1-IN 14DIP
|
7400 | Tube | Discontinued at | Inverter | 1 | Open Collector | 4.75V ~ 5.25V | -, 16mA | 0.8V | 2V |
|
SN7432NG4
IC GATE OR 4CH 2-INP 14DIP
|
7400 | Tube | Discontinued at | OR Gate | 2 | - | 4.75V ~ 5.25V | 800µA, 16mA | 0.8V | 2V |
|
SN74LVC14AQDRG4Q1
IC INV SCHMITT 6CH 1-IN 14SOIC
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 3.6V | 24mA, 24mA | 0.4V ~ 0.8V | 2V |
|
SN74LVC2G06QDCKRQ1
IC INVERTER OD 2CH 2-INP SC70-6
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | Inverter | 2 | Open Drain | 1.65V ~ 5.5V | -, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
5962-9758401QDA
MILITARY 2-CH, 4-INPUT, 4.5-V TO
|
54F | Tube | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
|
M38510/33003BCA
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54F | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN7416NSR
IC INV OPEN COL 6CH 1-IN 14SOP
|
7400 | Tape & Reel (TR) | Active | Inverter | 1 | Open Collector | 4.75V ~ 5.25V | -, 40mA | 0.8V | 2V |
|
SN74ALVC10PWRG4
IC GATE NAND 3CH 3-INP 14TSSOP
|
74ALVC | Tape & Reel (TR) | Discontinued at | NAND Gate | 3 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74LVC32AQPWRG4Q1
IC GATE OR 4CH 2-INP 14TSSOP
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | OR Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
|
SN54F30J
IC GATE NAND 1CH 8-INP 14CDIP
|
54F | Tube | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN7406DRE4
IC INVERTER OPEN 6CH 1-IN 14SOIC
|
7400 | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Open Collector | 4.75V ~ 5.25V | -, 40mA | 0.8V | 2V |
