| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN7400NE4
4-CH, 2-INPUT, 4.75-V TO 5.25-V
|
7400 | Tube | Active | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
|
SNJ54ALS133J
IC GATE NAND 1CH 13-INP 16CDIP
|
54ALS | Tube | Active | NAND Gate | 13 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN7402N
IC GATE NOR 4CH 2-INP 14DIP
|
7400 | Tube | Active | NOR Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
|
M38510/37401B2A
IC GATE AND 4CH 2-INP 20LCCC
|
54ALS | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74LVC86AQPWRG4Q1
IC GATE XOR 4CH 2-INP 14TSSOP
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
|
SNJ54ALS30AJ
IC GATE NAND 1CH 8-INP 14CDIP
|
54ALS | Tube | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74ALVC08D
IC GATE AND 4CH 2-INP 14SOIC
|
74ALVC | Bulk | Active | AND Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AS11N
IC GATE AND 3CH 3-INP 14DIP
|
74AS | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
SN7406D
IC INVERTER OPEN 6CH 1-IN 14SOIC
|
7400 | Bulk | Active | Inverter | 1 | Open Collector | 4.75V ~ 5.25V | -, 40mA | 0.8V | 2V |
|
SN74AS10N
IC GATE NAND 3CH 3-INP 14DIP
|
74AS | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
SN74S37NSR
IC GATE NAND 4CH 2-INP 14SOP
|
74S | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 4.75V ~ 5.25V | 3mA, 60mA | 0.8V | 2V |
|
|
JM54AC05BDA-RH
54AC05 - HEX INVERTER WITH UPEN
|
54AC | Bulk | Active | Inverter | 1 | Open Drain | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
