| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SNJ54S00FK
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54S | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HCS7002QPWRQ1
IC GATE NOR 4CH 2-INP 14TSSOP
|
Automotive, AEC-Q100, 74HCS | Tape & Reel (TR) | Active | NOR Gate | 2 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
|
SN54S30J
MILITARY SINGLE 8-INPUT, 4.5-V T
|
54S | Tube | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74HCS04QDRQ1
IC INV SCHMITT 6CH 1-IN 14SOIC
|
Automotive, AEC-Q100, 74HCS | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
SN74HCS4075DR
IC GATE OR SCHMIT 3CH 3IN 14SOIC
|
Automotive, AEC-Q100, 74HCS | Tape & Reel (TR) | Active | OR Gate | 3 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
SN74HCS86DYYR
4-CH, 2-INPUT, 2-V TO 6-V 5.2 MA
|
74HCS | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
|
SNJ54S140W
MILITARY 2-CH, 4-INPUT, 4.5-V TO
|
54S | Tube | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | - | 0.8V | 2V |
|
SN74HCS86PWR
IC GATE XOR 4CH 2-INP 14TSSOP
|
74HCS | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | Schmitt Trigger | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
|
5962-8687101CA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54ALS | Tube | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 12mA | 0.7V | 2V |
|
SN74LVC2G08QDCURQ1
IC GATE AND 2CH 2-INP 8VSSOP
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
M38510/37006B2A
IC INVERTER 6CH 6-INP 20LCCC
|
54ALS | Tube | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74LVC1G11IDCKRQ1
IC GATE AND 1CH 3-INP SC70-6
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | AND Gate | 3 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
