| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74HCS20DR
IC LOGIC GATES
|
74HCS | Tape & Reel (TR) | Active | NAND Gate | 4 | Schmitt Trigger Input | 2V ~ 6V | -, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
SN74HC02N-P2
PROTOTYPE
|
74HC | Bulk | Active | NOR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
JM38510/07005BCA
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54S | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
SN74LVC1G86DCKRE4
IC GATE XOR 1CH 2-INP SC70-5
|
74LVC | Tape & Reel (TR) | Discontinued at | XOR (Exclusive OR) | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AUC00RGYR
IC GATE NAND 4CH 2-INP 14VQFN
|
74AUC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 0.8V ~ 2.7V | 9mA, 9mA | 0V ~ 0.7V | 1.7V |
|
SN74LVC1G08QDCKRQ1
IC GATE AND 1CH 2-INP SC70-5
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | - | - |
|
SN74LVC2G08DCTRG4
IC GATE AND 2CH 2-INP SM8
|
74LVC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
5962-8404701VCA
54HC08 QUADRUPLE 2-INPUT POSITIV
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
CD74HC10MG4
IC GATE NAND 3CH 3-INP 14SOIC
|
74HC | Tube | Discontinued at | NAND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74AUC1G14YZAR
IC INVERT SCHMITT 1CH 1IN 5DSBGA
|
74AUC | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 0.8V ~ 2.7V | 9mA, 9mA | 0.22V ~ 0.58V | 0.5V ~ 1.56V |
|
SN74AHCT02NS
IC GATE NOR 4CH 2-INP 14-SO
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
SNJ54S32W
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54S | Tube | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
