| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
74LCX00TTR
IC GATE NAND 4CH 2-INP 14TSSOP
|
74LCX | Tape & Reel (TR) | Obsolete | NAND Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
74AC08B
IC GATE AND 4CH 2-INP 14DIP
|
74AC | Tube | Obsolete | AND Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
74LCX00YTTR
IC GATE NAND 4CH 2-INP 14TSSOP
|
Automotive, AEC-Q100, 74LCX | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
74AC02MTR
IC GATE NOR 4CH 2-INP 14SO
|
74AC | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
HCF4049UM013TR
IC INVERTER 6CH 1-INP 16SO
|
4000 | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 3V ~ 20V | 12mA, 48mA | 1V ~ 3V | 4V ~ 12V |
|
|
M74HC02B1R
IC GATE NOR 4CH 2-INP 14DIP
|
74HC | Tube | Obsolete | NOR Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
HCF4025M013TR
IC GATE NOR 3CH 3-INP 14SO
|
4000 | Tape & Reel (TR) | Obsolete | NOR Gate | 3 | - | 3V ~ 20V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
M74HC08YTTR
LOGIC IC'S
|
74HC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
M74HCT00B1R
IC GATE NAND 4CH 2-INP 14DIP
|
74HCT | Tube | Obsolete | NAND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
|
74VHC02MTR
IC GATE NOR 4CH 2-INP 14SO
|
74VHC | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V | 1.5V |
|
74V1T14STR
IC INVERTER 1CH 1-INP SOT23-5
|
74V | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 2V |
|
|
M74HC133RM13TR
IC GATE NAND 1CH 13-INP 16SO
|
74HC | Tape & Reel (TR) | Obsolete | NAND Gate | 13 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
