| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
74LVQ04MTR
IC INVERTER 6CH 1-INP 14SO
|
74LVQ | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
74V1G32CTR
IC GATE OR 1CH 2-INP SOT323-5
|
74V | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V | 1.5V |
|
74LVXU04TTR
IC INVERTER 6CH 1-INP 14TSSOP
|
74LVX | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 2V ~ 3.6V | 4mA, 4mA | 0.3V | 1.7V |
|
|
74VHCT08ATTR
IC GATE AND 4CH 2-INP 14TSSOP
|
74VHCT | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
74VHCT86AMTR
IC GATE XOR 4CH 2-INP 14SO
|
74VHCT | Tape & Reel (TR) | Obsolete | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
74ACT14TTR
IC INVERTER 6CH 1-INP 14TSSOP
|
74ACT | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 24mA, 24mA | 0.6V | 2V |
|
|
74VHCT32AMTR
IC GATE OR 4CH 2-INP 14SO
|
74VHCT | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
74VHC14YMTR
IC INVERT SCHMITT 6CH 1-INP 14SO
|
Automotive, AEC-Q100, 74VHC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
HCF4049UBEY
IC INVERTER 6CH 1-INP 16DIP
|
4000B | Tube | Obsolete | Inverter | 1 | - | 3V ~ 20V | 12mA, 48mA | 1V ~ 3V | 4V ~ 12V |
|
M74HC4075B1R
IC GATE OR 3CH 3-INP 14DIP
|
74HC | Tube | Obsolete | OR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
74AC08MTR
IC GATE AND 4CH 2-INP 14SO
|
74AC | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
HCF4069UBEY
IC INVERTER 6CH 1-INP 14DIP
|
4000B | Tube | Obsolete | Inverter | 1 | - | 3V ~ 20V | 6.8mA, 6.8mA | 1V ~ 2.5V | 4V ~ 12.5V |
