| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74HC132ANSR
IC GATE NAND SCHMIT 4CH 2IN 14SO
|
74HC | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.1V ~ 0.26V | 1.9V ~ 5.9V |
|
SN74HC10PWE4
IC GATE NAND 3CH 3-INP 14TSSOP
|
74HC | Bulk | Discontinued at | NAND Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LVC14AQPWREP
IC INVERTER 6CH 1-INP 14TSSOP
|
74LVC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 3.6V | 24mA, 24mA | 0.4V ~ 0.8V | 2V |
|
SN74LS14D
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74LS | Tube | Active | Inverter | 1 | Schmitt Trigger | 4.75V ~ 5.25V | 400µA, 8mA | 0.5V | 1.9V |
|
54LS08FM
AND GATE, TTL
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74HC08PWRE4
IC GATE AND 4CH 2-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Obsolete | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LVC2G02YEAR
IC GATE NOR 2CH 2-INP 8DSBGA
|
74LVC | Tape & Reel (TR) | Obsolete | NOR Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
SN74LS32NSR
IC GATE OR 4CH 2-INP 14SOP
|
74LS | Tape & Reel (TR) | Active | OR Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
|
74LS266SCX
NOR GATE
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
SN74LS33N
IC GATE NOR OP COL 4CH 2IN 14DIP
|
74LS | Tube | Active | NOR Gate | 2 | Open Collector | 4.75V ~ 5.25V | -, 24mA | 0.8V | 2V |
|
54LS11LM
AND GATE, LS SERIES, 3 FUNC, 3-I
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
CD74HC21M
IC GATE AND 2CH 4-INP 14SOIC
|
74HC | Bulk | Discontinued at | AND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
