| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
84039012A
MILITARY 2-CH, 4-INPUT, 2-V TO 6
|
54HC | Tube | Active | NAND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
SN54HC04J
IC INVERTER 6CH 6-INP 14CDIP
|
54HC | Tube | Active | Inverter | 6 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
M38510/65701B2A
IC INVERTER 6CH 6-INP 20LCCC
|
54HC | Tube | Active | Inverter | 6 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
CD54HC4075F3A
MILITARY 3-CH, 3-INPUT, 2-V TO 6
|
54HC | Tube | Active | OR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
CD54HC21F3A
MILITARY 2-CH, 4-INPUT, 2-V TO 6
|
54HC | Tube | Active | AND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
8404201DA
MILITARY 3-CH, 3-INPUT, 2-V TO 6
|
54HC | Tube | Active | NOR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
74AC11086D
IC GATE XOR 4CH 2-INP 16SOIC
|
74AC | Tube | Active | XOR (Exclusive OR) | 2 | - | 3V ~ 5.5V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74AC11D
IC GATE AND 3CH 3-INP 14SOIC
|
74AC | Tube | Discontinued at | AND Gate | 3 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74AC32N
IC GATE OR 4CH 2-INP 14DIP
|
74AC | Tube | Active | OR Gate | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
CD74AC00M96
IC GATE NAND 4CH 2-INP 14SOIC
|
74AC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 1.5V ~ 5.5V | 24mA, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
|
SNJ54HC4002J
IC GATE NOR 2CH 4-INP 14CDIP
|
54HC | Tube | Active | NOR Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
74AC11008DR
IC GATE AND 4CH 2-INP 16SOIC
|
74AC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 3V ~ 5.5V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
