| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
74H01PC
NAND GATE, TTL, PDIP14
|
- | Bulk | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | 250µA, 20mA | 0.8V | 2V |
|
SNJ54LS132J
IC GATE NAND 4CH 2-INP 14CDIP
|
54LS | Tube | Active | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 400µA, 4mA | 1V | 1.9V |
|
CD74HCT21E
IC GATE AND 2CH 4-INP 14DIP
|
74HCT | Tube | Active | AND Gate | 4 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74HCT14DT
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74HCT | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 4mA, 4mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
SN74HCT02PW
IC GATE NOR 4CH 2-INP 14TSSOP
|
74HCT | Tube | Discontinued at | NOR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
SN74AC11008PWLE
AND GATE, AC SERIES
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
|
DM5430W/883
NAND GATE
|
- | Bulk | Active | NAND Gate | 8 | - | 4.5V ~ 5.5V | 400µA, 16mA | 0.8V | 2V |
|
|
SN54HC00TDF2
IC GATE NAND 4CH 2-INP DIE
|
- | Tube | Active | NAND Gate | 2 | - | - | - | - | - |
|
|
SN54AC02VTD1
IC GATE NOR 4CH 2-INP DIE
|
- | Tube | Active | NOR Gate | 2 | - | 1.5V ~ 5.5V | - | - | - |
|
|
4001BDC
NOR GATE, CMOS
|
- | Bulk | Active | NOR Gate | 2 | - | - | - | - | - |
|
CD74HCT32M96
IC GATE OR 4CH 2-INP 14SOIC
|
74HCT | Tape & Reel (TR) | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
CD4001UBF3A
CD4001UB-MIL CMOS QUAD 2-INPUT N
|
- | Bulk | Active | - | - | - | - | - | - | - |
