| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DM54LS21J/883
AND GATE, LS SERIES
|
- | Bulk | Active | AND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
SN74AHCT14N
IC INVERT SCHMITT 6CH 1-IN 14DIP
|
74AHCT | Tube | Active | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
JM4001BBDA
QUAD 2 INPUT NOR BUFFERED B SERI
|
- | Bulk | Active | NOR Gate | 2 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74AHCT00RGYR
IC GATE NAND 4CH 2-INP 14VQFN
|
74AHCT | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74AHCT14PWR
IC INVERTER 6CH 1-INP 14TSSOP
|
74AHCT | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
100121DCQR
INVERTER, 100K SERIES
|
- | Bulk | Active | Inverter | 9 | - | 4.2V ~ 5.7V | - | 1.49V | 0.88V |
|
SN74AHCT04D
IC INVERTER 6CH 1-INP 14SOIC
|
74AHCT | Tube | Discontinued at | Inverter | 1 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74AHCT02DGVR
IC GATE NOR 4CH 2-INP 14TVSOP
|
74AHCT | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
54LS38FM
NAND GATE, TTL
|
- | Bulk | Active | - | - | - | - | - | - | - |
|
CD4025BEE4
3-CH, 3-INPUT, 3-V TO 18-V NOR G
|
- | Tube | Active | NOR Gate | 3 | - | 3V ~ 18V | 6.8mA, 6.8mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74AHCT08PWG4
IC GATE AND 4CH 2-INP 14TSSOP
|
74AHCT | Tube | Obsolete | AND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74AHCT14PW
IC INVERTER 6CH 1-INP 14TSSOP
|
74AHCT | Tube | Discontinued at | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
