| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD74ACT08ME4
IC GATE AND 4CH 2-INP 14SOIC
|
74ACT | Tube | Discontinued at | AND Gate | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
SN74ACT86D
IC GATE XOR 4CH 2-INP 14SOIC
|
74ACT | Tube | Discontinued at | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
74ACT11030DE4
IC GATE NAND 1CH 8-INP 14SOIC
|
74ACT | Tube | Discontinued at | NAND Gate | 8 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
74ACT11032PWE4
IC GATE OR 4CH 2-INP 16TSSOP
|
74ACT | Tube | Obsolete | OR Gate | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
SN74ACT04PWRQ1
AUTOMOTIVE, 4.5V-TO-5.5V, HEX IN
|
74ACT | Tape & Reel (TR) | Active | Inverter | 6 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
V62/06620-01XE
IC GATE XOR 4CH 2-INP 14SOIC
|
74ACT | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
|
SN74ACT00DRG4
IC GATE NAND 4CH 2-INP 14SOIC
|
74ACT | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
CD74ACT00MG4
IC GATE NAND 4CH 2-INP 14SOIC
|
74ACT | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
74ACT11032NG4
IC GATE OR 4CH 2-INP 16DIP
|
74ACT | Tube | Discontinued at | OR Gate | 2 | - | 4.5V ~ 5.5V | 24mA, 24mA | 0.8V | 2V |
|
CD74HCT08EE4
IC INVERTER 6CH 6-INP 14DIP
|
74HCT | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
CD74HCT04E
IC INVERTER 6CH 1-INP 14DIP
|
74HCT | Tube | Active | Inverter | 1 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
|
SN74HCT00DR
IC GATE NAND 4CH 2-INP 14SOIC
|
74HCT | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
