| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74S05DRE4
IC INVERTER OPEN 6CH 1-IN 14SOIC
|
74S | Tape & Reel (TR) | Obsolete | Inverter | 1 | Open Collector | 4.75V ~ 5.25V | -, 20mA | 0.8V | 2V |
|
5962-9752801QDA
MILITARY 4-CH, 2-INPUT, 2-V TO 5
|
54AHC | Tube | Active | NOR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
CD74AC02E-NG
PROTOTYPE
|
74AC | Bulk | Active | NOR Gate | 2 | - | 1.5V ~ 5.5V | 24mA, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
SN74LVC1G06DCKTG4
IC BUFFER INVERT 5.5V SC70-5
|
74LVC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Open Drain | 1.65V ~ 5.5V | -, 32mA | 0.58V ~ 1.65V | 1.07V ~ 3.85V |
|
SN74LVC1G08MDBVREP
IC GATE AND 1CH 2-INP SOT23-5
|
74LVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | - | - |
|
SN74S32NSR
IC GATE OR 4CH 2-INP 14SOP
|
74S | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
|
SN74LVC1G11DBVR-P3
PROTOTYPE
|
74LVC | Bulk | Active | AND Gate | 3 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
CAHCT1G00QDCKRQ1
IC GATE NAND 1CH 2-INP SC70-5
|
Automotive, AEC-Q100, 74AHCT | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74LVC1G132DBVR
IC GATE NAND 1CH 2-INP SOT23-5
|
74LVC | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 1.65V ~ 5.5V | 32mA, 32mA | 0.39V ~ 1.87V | 1.16V ~ 3.33V |
|
74AC11000NSR
IC GATE NAND 4CH 2-INP 16SO
|
74AC | Bulk | Discontinued at | NAND Gate | 2 | - | 3V ~ 5.5V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74AC16PWR
1.5V TO 6V INVERTER WITH SCHMITT
|
74AC | Tape & Reel (TR) | Active | Inverter | 6 | Schmitt Trigger Input, Open Drain | 1.5V ~ 6V | -, 24mA | 0.7V ~ 2.3V | 1.17V ~ 3.9V |
|
SN74S04NSR
IC INVERTER 6CH 1-INP 14SOP
|
74S | Tape & Reel (TR) | Active | Inverter | 1 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
