| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74HC30D
IC GATE XNOR 4CH 2-INP 14SO
|
74HC | Bulk | Active | XNOR (Exclusive NOR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
SN74AS27DRG4
IC GATE NOR 3CH 3-INP 14SOIC
|
74AS | Tape & Reel (TR) | Obsolete | NOR Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
SN74AHC08PWRG4
IC GATE AND 4CH 2-INP 14TSSOP
|
74AHC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74HC08NSR
IC GATE AND 4CH 2-INP 14SOP
|
74HC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LS136DR
IC GATE XOR OPEN 4CH 2-IN 14SOIC
|
74LS | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | Open Collector | 4.75V ~ 5.25V | -, 8mA | 0.8V | 2V |
|
SN74HC27DBR
IC GATE NOR 3CH 3-INP 14SSOP
|
74HC | Tape & Reel (TR) | Active | NOR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LS11D
IC GATE AND 3CH 3-INP 14SOIC
|
74LS | Tube | Active | AND Gate | 3 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SNJ54AHC14J
MILITARY 6-CH, 2-V TO 5.5-V INVE
|
74AHC | Tube | Active | Inverter | 6 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 1.9V ~ 3.35V | 2.2V ~ 3.85V |
|
|
SN74HC05ANSR
IC INVERTER OD 6CH 1-INP 14SO
|
74HC | Tape & Reel (TR) | Active | Inverter | 1 | Open Drain | 2V ~ 6V | -, 5.2mA | 0.1V ~ 0.26V | - |
|
|
SN74LS86ANE4
4-CH, 2-INPUT, 4.75-V TO 5.25-V
|
74LS | Tube | Active | XOR (Exclusive OR) | 2 | - | 4.75V ~ 5.25V | 800µA, 16mA | 0.8V | 2V |
|
DM74S11J
AND GATE, TTL
|
74S | Bulk | Active | AND Gate | 3 | - | 4.5V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
|
SN74AHC04QDRG4
IC INVERTER 6CH 1-INP 14SOIC
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
