| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
CD40106BF
MILITARY 6-CH, 3-V TO 18-V INVER
|
4000B | Tube | Active | Inverter | 6 | Schmitt Trigger | 3V ~ 18V | 6.8mA, 6.8mA | 0.9V ~ 4V | 3.6V ~ 10.8V |
|
SN74F11D
IC GATE AND 3CH 3-INP 14SOIC
|
74F | Tube | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
74H30PC
NAND GATE, TTL, PDIP14
|
- | Bulk | Active | NAND Gate | 8 | - | 4.75V ~ 5.25V | - | - | - |
|
SN74AHC1G04QDBVRQ1
IC INVERTER 1CH 1-INP SOT23-5
|
Automotive, AEC-Q100, 74AHC | Tape & Reel (TR) | Active | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74F20DRE4
IC GATE NAND 2CH 4-INP 14SOIC
|
74F | Tape & Reel (TR) | Discontinued at | NAND Gate | 4 | - | 4.5V ~ 5.5V | 1mA, 20mA | 0.8V | 2V |
|
DM54LS86J/883
XOR GATE, LS SERIES TTL
|
- | Bulk | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
SN74ALS32DB
OR GATE 4-ELEMENT 2-IN BIPOLAR 1
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
CD74HC08M96
IC GATE AND 4CH 2-INP 14SOIC
|
74HC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
54S133FM
NAND GATE, TTL
|
- | Bulk | Active | NAND Gate | 13 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
|
SN74LVC14ADR
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74LVC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 1.65V ~ 3.6V | 24mA, 24mA | 0.15V ~ 0.8V | 1.3V ~ 2V |
|
|
SN74AS10DR
IC GATE NAND 3CH 3-INP 14SOIC
|
74AS | Tape & Reel (TR) | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 2mA, 20mA | 0.8V | 2V |
|
SN74LVC3G04DCUT
IC INVERTER 3CH 3-INP 8VSSOP
|
74LVC | Tape & Reel (TR) | Active | Inverter | 3 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
