| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LS00NSR
IC GATE NAND 4CH 2-INP 14SOP
|
74LS | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74LV06ADGVR
IC INVERTER OD 6CH 1-INP 14TVSOP
|
74LV | Tape & Reel (TR) | Active | Inverter | 1 | Open Drain | 2V ~ 5.5V | -, 16mA | 0.5V | 1.5V |
|
SN74LS02DE4
IC GATE NOR 4CH 2-INP 14SOIC
|
74LS | Tube | Discontinued at | NOR Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
SN74AHCT1G32DCKR
IC GATE OR 1CH 2-INP SC70-5
|
74AHCT | Tape & Reel (TR) | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN7404DR
IC INVERTER 6CH 1-INP 14SOIC
|
7400 | Tape & Reel (TR) | Active | Inverter | 1 | - | 4.75V ~ 5.25V | 400µA, 16mA | 0.8V | 2V |
|
SN74LV27APWR
IC GATE NOR 3CH 3-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Active | NOR Gate | 3 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
|
SN74AHCT32DGVR
IC GATE OR 4CH 2-INP 14TVSOP
|
74AHCT | Tape & Reel (TR) | Active | OR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74LV20AD
IC GATE NAND 2CH 4-INP 14SOIC
|
74LV | Tube | Active | NAND Gate | 4 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
M38510/00105BDA
IC INVERTER 6CH 1-INP 14CFP
|
- | Bulk | Active | Inverter | 1 | - | 4.5V ~ 5.5V | 400µA, 16mA | 0.8V | 2V |
|
SN74LS14DE4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74LS | Tube | Discontinued at | Inverter | 1 | Schmitt Trigger | 4.75V ~ 5.25V | 400µA, 8mA | 0.5V | 1.9V |
|
CD4009UBF3A
IC INVERTER 6CH 6-INP 16CDIP
|
- | Tube | Active | Inverter | 6 | - | 3V ~ 18V | 3mA, 36mA | 1V ~ 2.5V | 4V ~ 12.5V |
|
|
SN74LV02APWR
IC GATE NOR 4CH 2-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
