| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DM74S11J
AND GATE, TTL
|
74S | Bulk | Active | AND Gate | 3 | - | 4.5V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SN74AHC04QDRG4
IC INVERTER 6CH 1-INP 14SOIC
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74HCS14QDRQ1
IC INV SCHMITT 6CH 1-IN 14SOIC
|
Automotive, AEC-Q100, 74HCS | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
SN74AHC1G08IDBVRSV
PROTOTYPE
|
74AHC | Bulk | Active | AND Gate | 2 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74LS86ANG4
IC GATE XOR 4CH 2-INP 14DIP
|
74LS | Tube | Discontinued at | XOR (Exclusive OR) | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74HCS21QPWRQ1
IC GATE AND 2CH 4-INP 14TSSOP
|
Automotive, AEC-Q100, 74HCS | Tape & Reel (TR) | Active | AND Gate | 4 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
SN74LS05NG4
IC INV OPEN COL 6CH 1-IN 14DIP
|
74LS | Tube | Discontinued at | Inverter | 1 | Open Collector | 4.75V ~ 5.25V | -, 8mA | 0.8V | 2V |
|
|
CD4012BM96
IC GATE NAND 2CH 4-INP 14SOIC
|
4000B | Tape & Reel (TR) | Active | NAND Gate | 4 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74HC14DRE4
IC INV SCHMITT 6CH 1-IN 14SOIC
|
74HC | Tape & Reel (TR) | Obsolete | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
SN74HCS10QPWRQ1
IC GATE NAND 3CH 3-INP 14TSSOP
|
Automotive, AEC-Q100, 74HCS | Tape & Reel (TR) | Active | NAND Gate | 3 | Schmitt Trigger Input | 2V ~ 6V | 7.8mA, 7.8mA | 1V ~ 3V | 1.5V ~ 4.2V |
|
CD4049UBDR
IC INVERTER 6CH 1-INP 16SOIC
|
4000B | Tape & Reel (TR) | Active | Inverter | 1 | - | 3V ~ 18V | 4.3mA, 24mA | 1V ~ 2.5V | 4V ~ 12.5V |
|
SN74LS21DR
IC GATE AND 2CH 4-INP 14SOIC
|
74LS | Tape & Reel (TR) | Active | AND Gate | 4 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
