| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
M38510/30001SDA
SPACE 4-CH, 2-INPUT, 4.5-V TO 5.
|
54LS | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74LVC86AD
IC GATE XOR 4CH 2-INP 14SOIC
|
74LVC | Tube | Active | XOR (Exclusive OR) | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
54LS11FM
AND GATE, TTL
|
54LS | Bulk | Active | AND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
SN74LVC2G04DCKT
IC INVERTER 2CH 2-INP SC70-6
|
74LVC | Tape & Reel (TR) | Active | Inverter | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
SN74HC08QDRG4Q1
IC GATE AND 4CH 2-INP 14SOIC
|
Automotive, AEC-Q100, 74HC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
CD74HC4075PWT
IC GATE OR 3CH 3-INP 14TSSOP
|
74HC | Tape & Reel (TR) | Discontinued at | OR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LVC08AMPWREP
IC GATE AND 4CH 2-INP 14TSSOP
|
74LVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
|
SN74LVC02AD
IC GATE NOR 4CH 2-INP 14SOIC
|
74LVC | Tube | Active | NOR Gate | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74H01N3
NAND GATE, TTL, PDIP14
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
CD74HC27E
IC GATE NOR 3CH 3-INP 14DIP
|
74HC | Tube | Active | NOR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
|
JM38510/31004SDA
SPACE 4-CH, 2-INPUT, 4.5-V TO 5.
|
54LS | Tube | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
M38510/30302B2A
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54LS | Tube | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
