| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP1SGX10DF672C6N
IC FPGA 362 I/O 672FBGA
|
Stratix® GX | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 672-BBGA | 672-FBGA (27x27) | Not Verified | 10570 |
|
EP4SGF35I3NAA
IC FPGA 1152FBGA
|
Stratix® IV GF | Tray | Obsolete | 0.86V ~ 1.15V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | - |
|
HC1S80F1020NAYP
IC FPGA 782 I/O 1020FBGA
|
Stratix® HardCopy® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | - | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 79040 |
|
HC1S80F1020AYR
IC FPGA 782 I/O 1020FBGA
|
Stratix® HardCopy® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | - | 1020-BBGA | 1020-FBGA (33x33) | Not Verified | 79040 |
|
HC1S30F780AB
IC FPGA 597 I/O 780FBGA
|
Stratix® HardCopy® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | - | 780-BBGA, FCBGA | 780-FBGA (29x29) | Not Verified | 32470 |
|
EP2SGX60CF780C3
IC FPGA 364 I/O 780FBGA
|
Stratix® II GX | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BBGA | 780-FBGA (29x29) | Not Verified | 60440 |
|
EP1AGX90EF1152I6
IC FPGA 538 I/O 1152FBGA
|
Arria GX | Tray | Obsolete | 1.15V ~ 1.25V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA | 1152-FBGA (35x35) | Not Verified | 90220 |
|
10AT090S2F45E2SG
IC FPGA 624 I/O 1932FBGA
|
Arria 10 GT | Tray | Active | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 100°C (TJ) | 1932-BBGA, FCBGA | 1932-FBGA, FC (45x45) | Not Verified | 900000 |
|
EP2AGZ350HF40I4N
IC FPGA 734 I/O 1517FBGA
|
Arria II GZ | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 348500 |
|
EP1M350F780C7ES
IC FPGA 486 I/O 780FBGA
|
Mercury | Tray | Obsolete | 1.71V ~ 1.89V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BBGA, FCBGA | 780-FBGA (29x29) | Not Verified | 14400 |
|
5SGTMC7K3F40C2N
IC FPGA 600 I/O 1517FBGA
|
Stratix® V GT | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 622000 |
|
5CGTFD7D5F27C7N
IC FPGA 336 I/O 672FBGA
|
Cyclone® V GT | Tray | Active | 1.07V ~ 1.13V | Surface Mount | 0°C ~ 85°C (TJ) | 672-BGA | 672-FBGA (27x27) | Not Verified | 149500 |
