| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP3CLS100F484C8N
IC FPGA 278 I/O 484FBGA
|
Cyclone® III | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BGA | 484-FBGA (23x23) | Not Verified | 100448 |
|
|
EP3CLS100U484C8
IC FPGA 278 I/O 484UBGA
|
Cyclone® III | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 484-FBGA | 484-UBGA (19x19) | Not Verified | 100448 |
|
EP4CE115F29C7N
IC FPGA 528 I/O 780FBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BGA | 780-FBGA (29x29) | Not Verified | 114480 |
|
|
EP4CE40F23C7N
IC FPGA 328 I/O 484FBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BGA | 484-FBGA (23x23) | Not Verified | 39600 |
|
EP4CE22F17C7N
IC FPGA 153 I/O 256FBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 256-LBGA | 256-FBGA (17x17) | Not Verified | 22320 |
|
|
EP4CE10F17C8
IC FPGA 179 I/O 256FBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 256-LBGA | 256-FBGA (17x17) | Not Verified | 10320 |
|
EP4CE15F23I8L
IC FPGA 343 I/O 484FBGA
|
Cyclone® IV E | Tray | Active | 0.97V ~ 1.03V | Surface Mount | -40°C ~ 100°C (TJ) | 484-BGA | 484-FBGA (23x23) | Not Verified | 15408 |
|
EP4CE30F23C9LN
IC FPGA 328 I/O 484FBGA
|
Cyclone® IV E | Tray | Active | 0.97V ~ 1.03V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BGA | 484-FBGA (23x23) | Not Verified | 28848 |
|
|
EP4CE22F17C9L
IC FPGA 153 I/O 256FBGA
|
Cyclone® IV E | Tray | Active | 0.97V ~ 1.03V | Surface Mount | 0°C ~ 85°C (TJ) | 256-LBGA | 256-FBGA (17x17) | Not Verified | 22320 |
|
EP4CE75F29C8LN
IC FPGA 426 I/O 780FBGA
|
Cyclone® IV E | Tray | Active | 0.97V ~ 1.03V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BGA | 780-FBGA (29x29) | Not Verified | 75408 |
|
EP4CE75F23C8
IC FPGA 292 I/O 484FBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | 0°C ~ 85°C (TJ) | 484-BGA | 484-FBGA (23x23) | Not Verified | 75408 |
|
EP4CE22F17A7N
IC FPGA 153 I/O 256FBGA
|
Cyclone® IV E | Tray | Active | 1.15V ~ 1.25V | Surface Mount | -40°C ~ 125°C (TJ) | 256-LBGA | 256-FBGA (17x17) | Not Verified | 22320 |
