| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
5SGSMD3E2H29C3WN
IC FPGA 360 I/O 780HBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BBGA, FCBGA | 780-HBGA (33x33) | Not Verified | 236000 |
|
5SGSMD8K1F40C2LG
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Active | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 695000 |
|
5AGZME7H3F35I4G
IC FPGA 534 I/O 1152FBGA
|
Arria V GZ | Tray | Active | 0.82V ~ 0.88V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 450000 |
|
10AX032E4F27E3LG
IC FPGA 240 I/O 672FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | 0°C ~ 100°C (TJ) | 672-BBGA, FCBGA | 672-FBGA, FC (27x27) | Not Verified | 320000 |
|
5SGSED8N2F46C2LN
IC FPGA STRATIX V GS FLIP CHIP
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | - | 0°C ~ 85°C (TJ) | - | - | Not Verified | 695000 |
|
5SGSED8N2F45C2LG
IC FPGA 840 I/O 1932FBGA
|
Stratix® V GS | Tray | Active | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1932-BBGA, FCBGA | 1932-FBGA, FC (45x45) | Not Verified | 695000 |
|
5AGZME7H3F35C4G
IC FPGA 534 I/O 1152FBGA
|
Arria V GZ | Tray | Active | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 450000 |
|
10AX057H2F34I1SG
IC FPGA 492 I/O 1152FCBGA
|
Arria 10 GX | Tray | Discontinued at | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FCBGA (35x35) | Not Verified | 570000 |
|
EP4SE230F35I4NAA
IC FPGA 1152FBGA
|
STRATIX® IV E | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 228000 |
|
|
10AX027H3F35I2SG
IC FPGA 384 I/O 1152FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.93V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA, FC (35x35) | Not Verified | 270000 |
|
10AX048E2F29I1HG
IC FPGA 360 I/O 780FBGA
|
Arria 10 GX | Tray | Active | 0.87V ~ 0.98V | Surface Mount | -40°C ~ 100°C (TJ) | 780-BBGA, FCBGA | 780-FBGA (29x29) | Not Verified | 480000 |
|
EP4SE820F43C3N
IC FPGA 1120 I/O 1760FCBGA
|
STRATIX® IV E | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 85°C (TJ) | 1760-BBGA, FCBGA | 1760-FCBGA (42.5x42.5) | Not Verified | 813050 |
