| Image | Mfr Part # | Series | Package | Product Status | Voltage - Supply | Mounting Type | Operating Temperature | Package / Case | Supplier Device Package | Programmable | Number of Logic Elements/Cells |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
EP20K200BI356-3
IC FPGA 277 I/O 356BGA
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | -40°C ~ 100°C (TJ) | 356-LBGA | 356-BGA (35x35) | Not Verified | 8320 |
|
5SGSMD3H2F35I3L
IC FPGA 432 I/O 1152FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | -40°C ~ 100°C (TJ) | 1152-BBGA, FCBGA | 1152-FBGA (35x35) | Not Verified | 236000 |
|
5SGSED8K3F40I3LN
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 695000 |
|
5SGSMD4E3H29C2N
IC FPGA 360 I/O 780HBGA
|
Stratix® V GS | Tray | Obsolete | 0.87V ~ 0.93V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BBGA, FCBGA | 780-HBGA (33x33) | Not Verified | 360000 |
|
EP20K400BI652-2V
IC FPGA 502 I/O 652BGA
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | -40°C ~ 100°C (TJ) | 652-BGA | 652-BGA (45x45) | Not Verified | 16640 |
|
EP20K200FI672-3
IC FPGA 672FBGA
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | -40°C ~ 100°C (TJ) | 672-BBGA | 672-FBGA (27x27) | Not Verified | 8320 |
|
|
5SGSMD8K2F40I3LN
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | -40°C ~ 100°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 695000 |
|
|
5SGSED6K3F40C2LN
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 583000 |
|
EP20K200FI484-3
IC FPGA 382 I/O 484FBGA
|
APEX-20K® | Tray | Obsolete | 2.375V ~ 2.625V | Surface Mount | -40°C ~ 100°C (TJ) | 484-BBGA | 484-FBGA (23x23) | Not Verified | 8320 |
|
|
5SGSMD3E3H29C2LN
IC FPGA 360 I/O 780HBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 780-BBGA, FCBGA | 780-HBGA (33x33) | Not Verified | 236000 |
|
EP1C3T100C7
IC FPGA 65 I/O 100TQFP
|
Cyclone® | Tray | Obsolete | 1.425V ~ 1.575V | Surface Mount | 0°C ~ 85°C (TJ) | 100-TQFP | 100-TQFP (14x14) | Not Verified | 2910 |
|
|
5SGSMD6K3F40C3N
IC FPGA 696 I/O 1517FBGA
|
Stratix® V GS | Tray | Obsolete | 0.82V ~ 0.88V | Surface Mount | 0°C ~ 85°C (TJ) | 1517-BBGA, FCBGA | 1517-FBGA (40x40) | Not Verified | 583000 |
