| Image | Mfr Part # | Series | Package | Product Status | Function | Delay to 1st Tap | Available Total Delays | Number of Independent Delays | Voltage - Supply | Mounting Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS1000H-75
DS1000 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 15ns | 75ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.295", 7.50mm Width) |
|
DS1135LU-300/T&R
IC DELAY LINE 300NS 8UMAX
|
- | Tape & Reel (TR) | Obsolete | Multiple, NonProgrammable | 300ns | 300ns | 3 | 2.7V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1100U-20+T
IC DELAY LINE 5TAP 20NS 8UMAX
|
- | Tape & Reel (TR) | Active | Nonprogrammable | 4ns | 20ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1010S-350
IC DELAY LINE 10TAP 350NS 16SOIC
|
- | Tube | Obsolete | Nonprogrammable | 35ns | 350ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1045S-3/T&R
IC DELAY LINE 16TAP 54NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | Multiple, Programmable | 9ns | 54ns | 2 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100Z-175
IC DELAY LINE 5TAP 175NS 8SOIC
|
- | Tube | Obsolete | Nonprogrammable | 35ns | 175ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1000M-20
DS1000 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 4ns | 20ns | 1 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
|
DS1007S-4
IC DELAY LINE PROG 16SOIC
|
- | Tube | Obsolete | Multiple, NonProgrammable | 4ns | 3ns ~ 10ns, 9ns ~ 40ns | 7 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100M-35
IC DELAY LINE 5TAP 35NS 8DIP
|
- | Tube | Obsolete | Nonprogrammable | 7ns | 35ns | 1 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
|
DS1110S-125+
IC DELAY LINE 10TAP 125NS 16SOIC
|
- | Tube | Active | Nonprogrammable | 12.5ns | 125ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1010S-125/T&R
IC DELAY LINE 10TAP 125NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 12.5ns | 125ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100LZ-75
IC DELAY LINE 5TAP 75NS 8SOIC
|
- | Tube | Obsolete | Nonprogrammable | 15ns | 75ns | 1 | 3V ~ 3.6V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
