| Image | Mfr Part # | Series | Package | Product Status | Function | Delay to 1st Tap | Available Total Delays | Number of Independent Delays | Voltage - Supply | Mounting Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS1100LZ-60+
IC DELAY LINE 5TAP 60NS 8SOIC
|
- | Tube | Active | Nonprogrammable | 12ns | 60ns | 1 | 3V ~ 3.6V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1000S-500
DS1000 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 100ns | 500ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100U-250+T
IC DELAY LINE 5TAP 250NS 8UMAX
|
- | Tape & Reel (TR) | Active | Nonprogrammable | 50ns | 250ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1020S-25+T&R
IC DEL LN 256TAP 73.75NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | Programmable | 10ns | 73.75ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1013S-20+T&R
IC DELAY LINE 20NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | Multiple, NonProgrammable | 20ns | 20ns | 3 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1005K-100
DS1005 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 20ns | 100ns | 1 | 4.75V ~ 5.25V | Through Hole | 14-DIP (0.300", 7.62mm) |
|
DS1100LU-150+
IC DELAY LINE 5TAP 150NS 8UMAX
|
- | Tube | Obsolete | Nonprogrammable | 30ns | 150ns | 1 | 3V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1100LU-50+
IC DELAY LINE 5TAP 50NS 8UMAX
|
- | Tube | Active | Nonprogrammable | 10ns | 50ns | 1 | 3V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1005S-125+
IC DELAY LINE 5TAP 125NS 16SOIC
|
- | Tube | Obsolete | Nonprogrammable | 25ns | 125ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1000H-75
DS1000 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 15ns | 75ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.295", 7.50mm Width) |
|
DS1135LU-300/T&R
IC DELAY LINE 300NS 8UMAX
|
- | Tape & Reel (TR) | Obsolete | Multiple, NonProgrammable | 300ns | 300ns | 3 | 2.7V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1100U-20+T
IC DELAY LINE 5TAP 20NS 8UMAX
|
- | Tape & Reel (TR) | Active | Nonprogrammable | 4ns | 20ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
