| Image | Mfr Part # | Series | Package | Product Status | Function | Delay to 1st Tap | Available Total Delays | Number of Independent Delays | Voltage - Supply | Mounting Type | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DS1100M-35
IC DELAY LINE 5TAP 35NS 8DIP
|
- | Tube | Obsolete | Nonprogrammable | 7ns | 35ns | 1 | 4.75V ~ 5.25V | Through Hole | 8-DIP (0.300", 7.62mm) |
|
DS1100Z-30/T&R
IC DELAY LINE 5TAP 30NS 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 6ns | 30ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1100LU-100+TR
DS1100 5-TAP (DELAY LINE)
|
- | Bulk | Active | Nonprogrammable | 20ns | 100ns | 1 | 3V ~ 3.6V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1100LC-201/T&R
IC DELAY LINE 5TAP 201NS 8SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 40.2ns | 201ns | 1 | 3V ~ 3.6V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1135Z-10
IC DELAY LINE 10NS 8SOIC
|
- | Tube | Discontinued at | Multiple, NonProgrammable | 10ns | 10ns | 3 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1110S-125+
IC DELAY LINE 10TAP 125NS 16SOIC
|
- | Tube | Active | Nonprogrammable | 12.5ns | 125ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1010S-125/T&R
IC DELAY LINE 10TAP 125NS 16SOIC
|
- | Tape & Reel (TR) | Obsolete | Nonprogrammable | 12.5ns | 125ns | 1 | 4.75V ~ 5.25V | Surface Mount | 16-SOIC (0.295", 7.50mm Width) |
|
DS1100LZ-75
IC DELAY LINE 5TAP 75NS 8SOIC
|
- | Tube | Obsolete | Nonprogrammable | 15ns | 75ns | 1 | 3V ~ 3.6V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1000Z-20
DS1000 5-TAP SILICON DELAY LINE
|
- | Bulk | Active | Nonprogrammable | 4ns | 20ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1004Z-2+
IC DELAY LINE 5TAP 13NS 8SOIC
|
- | Tube | Obsolete | Nonprogrammable | 5ns | 13ns | 1 | 4.75V ~ 5.25V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
|
DS1135U-10
IC DELAY LINE 10NS 8UMAX
|
- | Tube | Obsolete | Multiple, NonProgrammable | 10ns | 10ns | 3 | 4.75V ~ 5.25V | Surface Mount | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|
DS1100LZ-200+T
IC DELAY LINE 5TAP 200NS 8SOIC
|
- | Tape & Reel (TR) | Active | Nonprogrammable | 40ns | 200ns | 1 | 3V ~ 3.6V | Surface Mount | 8-SOIC (0.154", 3.90mm Width) |
