| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AHCT02PWR
IC GATE NOR 4CH 2-INP 14TSSOP
|
74AHCT | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
SN74AHCT132DG4
IC GATE NAND 4CH 2-INP 14SOIC
|
74AHCT | Tube | Discontinued at | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
SN5401J
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
- | Tube | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 16mA | 0.8V | 2V |
|
|
SN74AHCT86DR
IC GATE XOR 4CH 2-INP 14SOIC
|
74AHCT | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
SNJ54AC04W
MILITARY 6-CH, 2-V TO 6-V INVERT
|
54AC | Tube | Active | Inverter | 6 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
SN74LV86APWR
IC GATE XOR 4CH 2-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
SN74S37N
IC GATE NAND 4CH 2-INP 14DIP
|
74S | Bulk | Active | NAND Gate | 2 | - | 4.75V ~ 5.25V | 3mA, 60mA | 0.8V | 2V |
|
SN74HC7266N
IC GATE XNOR 4CH 2-INP 14DIP
|
74HC | Bulk | Active | XNOR (Exclusive NOR) | 2 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V |
|
|
SN74AHCT132D
IC GATE NAND 4CH 2-INP 14SOIC
|
74AHCT | Tube | Discontinued at | NAND Gate | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V |
|
|
SN74S32DR
IC GATE OR 4CH 2-INP 14SOIC
|
74S | Tape & Reel (TR) | Active | OR Gate | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
|
SN74LV32APWR
IC GATE OR 4CH 2-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Active | OR Gate | 2 | - | 2V ~ 5.5V | 12mA, 12mA | 0.5V | 1.5V |
|
SN74HC21NS
IC GATE AND 2CH 4-INP 14SOP
|
74HC | Bulk | Active | AND Gate | 4 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
