| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
9015FM
NOR GATE, TTL, CDFP16
|
- | Bulk | Active | NOR Gate | 10 | - | 4.5V ~ 5.5V | 1.32mA, 17.6mA | 0.9V | 1.7V |
|
SN74LVC14AQPWRQ1
IC INVERTER 6CH 1-INP 14TSSOP
|
Automotive, AEC-Q100, 74LVC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 3.6V | 24mA, 24mA | 0.4V ~ 0.8V | 2V |
|
SNJ5401J
IC GATE NAND 4CH 2-INP 14CDIP
|
- | Tube | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 250µA, 16mA | 0.8V | 2V |
|
|
SN74LVC1G08QDCKRHT
PROTOTYPE
|
Automotive, AEC-Q100, 74LVC | Bulk | Active | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
|
SNJ5438J
IC GATE NAND 4CH 2-INP 14CDIP
|
- | Tube | Active | NAND Gate | 2 | Open Collector | 4.5V ~ 5.5V | 250µA, 48mA | 0.8V | 2V |
|
DM54LS27W/883
NOR GATE, LS SERIES TTL
|
- | Bulk | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
SN74LS38N
IC GATE NAND OPEN 4CH 2-IN 14DIP
|
74LS | Tube | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | -, 24mA | 0.8V | 2V |
|
SN74LV05APWR
IC INVERTER OD 6CH 1-INP 14TSSOP
|
74LV | Tape & Reel (TR) | Active | Inverter | 1 | Open Drain | 2V ~ 5.5V | -, 12mA | 0.5V | 1.5V |
|
|
SNJ5414W
IC INVERT SCHMITT 6CH 6INP 14CFP
|
- | Tube | Active | Inverter | 6 | Schmitt Trigger | 4.5V ~ 5.5V | 800µA, 16mA | 1.1V | 2V |
|
DM5410J/883
GATE
|
- | Bulk | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 16mA | 0.8V | 2V |
|
SN7414DR
IC INV SCHMITT 6CH 1-IN 14SOIC
|
7400 | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 4.75V ~ 5.25V | 800µA, 16mA | 0.6V | 2V |
|
SN74LS00NSR
IC GATE NAND 4CH 2-INP 14SOP
|
74LS | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
