| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LS03N
IC GATE NAND OPEN 4CH 2-IN 14DIP
|
74LS | Tube | Active | NAND Gate | 2 | Open Collector | 4.75V ~ 5.25V | 250µA, 16mA | 0.8V | 2V |
|
SN74LS08D
IC GATE AND 4CH 2-INP 14SOIC
|
74LS | Tube | Active | AND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
|
SN74LS05DR
IC INVERTER OPEN 6CH 1-IN 14SOIC
|
74LS | Tape & Reel (TR) | Active | Inverter | 1 | Open Collector | 4.75V ~ 5.25V | -, 8mA | 0.8V | 2V |
|
SN74AC08WBQARQ1
AUTOMOTIVE, 4-CH, 2-INPUT, 2V TO
|
74AC | Tape & Reel (TR) | Active | - | - | - | - | - | - | - |
|
|
SN74LS266N
IC GATE XNOR OPEN 4CH 2-IN 14DIP
|
74LS | Tube | Active | XNOR (Exclusive NOR) | 2 | Open Collector | 4.75V ~ 5.25V | -, 8mA | 0.8V | 2V |
|
SN74HCT32PWRG4
IC GATE OR 4CH 2-INP 14TSSOP
|
74HCT | Tape & Reel (TR) | Obsolete | OR Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
|
SN74LS27N
IC GATE NOR 3CH 3-INP 14DIP
|
74LS | Tube | Active | NOR Gate | 3 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
54LS40FMQB
NAND GATE
|
54LS | Bulk | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 1.2mA, 12mA | 0.7V | 2V |
|
SN74LV132ADBR
IC GATE NAND 4CH 2-INP 14SSOP
|
74LV | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 2V ~ 5.5V | 12mA, 12mA | 0.75V ~ 1.5V | 1.75V ~ 3.5V |
|
CD4075BE
IC GATE OR 3CH 3-INP 14DIP
|
4000B | Tube | Active | OR Gate | 3 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74AUP1G06DBVR
IC INVERTER OD 1CH 1-INP SOT23-5
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | Open Drain | 0.8V ~ 3.6V | -, 4mA | 0.1V ~ 0.45V | 3.6V |
|
SN74AUP1T04DCKR
IC INVERTER GATE SGL SC70-5
|
74AUP | Tape & Reel (TR) | Active | Inverter | 1 | - | 2.3V ~ 3.6V | 4mA, 4mA | 0.35V ~ 0.5V | 1.1V ~ 1.19V |
