| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74AHC132DGVR
IC GATE NAND 4CH 2-INP 14TVSOP
|
74AHC | Tape & Reel (TR) | Active | NAND Gate | 2 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V |
|
CD4030BPW
IC GATE XOR 4CH 2-INP 14TSSOP
|
4000B | Tube | Active | XOR (Exclusive OR) | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
CD4011BE
IC GATE NAND 4CH 2-INP 14DIP
|
4000B | Tube | Active | NAND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
SN74AC86PW
IC GATE XOR 4CH 2-INP 14TSSOP
|
74AC | Tube | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
SN74LS11NE4
3-CH, 3-INPUT, 4.75-V TO 5.25-V
|
74LS | Tube | Active | AND Gate | 3 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74AUC1G14DCKR
IC INVERT SCHMITT 1CH 1IN SC70
|
74AUC | Tape & Reel (TR) | Active | Inverter | 1 | Schmitt Trigger | 0.8V ~ 2.7V | 9mA, 9mA | 0.22V ~ 0.58V | 0.5V ~ 1.56V |
|
|
SN74AHC1G04DCKR-P
PROTOTYPE
|
74AHC | Bulk | Active | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC08DRG4
IC GATE AND 4CH 2-INP 14SOIC
|
74AHC | Tape & Reel (TR) | Discontinued at | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74HCT00DG4
IC GATE NAND 4CH 2-INP 14SOIC
|
74HCT | Bulk | Discontinued at | NAND Gate | 2 | - | 4.5V ~ 5.5V | 4mA, 4mA | 0.8V | 2V |
|
|
CD4072BE
IC GATE OR 2CH 4-INP 14DIP
|
4000B | Tube | Active | OR Gate | 4 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
|
CD74AC05M
IC INVERTER OD 6CH 1-INP 14SOIC
|
74AC | Tube | Discontinued at | Inverter | 1 | Open Drain | 1.5V ~ 5.5V | -, 24mA | 0.3V ~ 1.65V | 1.2V ~ 3.85V |
|
CD4081BNSR
IC GATE AND 4CH 2-INP 14SOP
|
4000B | Tape & Reel (TR) | Active | AND Gate | 2 | - | 3V ~ 18V | 3.4mA, 3.4mA | 1.5V ~ 4V | 3.5V ~ 11V |
