| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LVC86ADG4
IC GATE XOR 4CH 2-INP 14SOIC
|
74LVC | Bulk | Active | XOR (Exclusive OR) | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.58V ~ 0.8V | 1.07V ~ 2V |
|
SN74S20NG4
IC GATE NAND 2CH 4-INP 14DIP
|
74S | Tube | Discontinued at | NAND Gate | 4 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SN74LVC1G04DCKJ
IC INVERTER 1CH 1-INP SC70-5
|
74LVC | Tape & Reel (TR) | Obsolete | Inverter | 1 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.58V ~ 1.65V | 1.07V ~ 3.85V |
|
SN74LVC86APWG4
IC GATE XOR 4CH 2-INP 14TSSOP
|
74LVC | Bulk | Discontinued at | XOR (Exclusive OR) | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SNJ54ALS00AJ
54ALS00A QUADRUPLE 2-INPUT POSIT
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
1P1G14MDBVREPG4
IC INVERTER 1CH 1-INP SOT23-5
|
74LVC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | Schmitt Trigger | 1.65V ~ 5.5V | 32mA, 32mA | 0.39V ~ 1.87V | 1.16V ~ 3.33V |
|
SN74LVC04AQDRCT
PROTOTYPE
|
74LVC | Bulk | Active | Inverter | 6 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74S20NE4
2-CH, 4-INPUT, 4.75-V TO 5.25-V
|
74S | Tube | Active | NAND Gate | 4 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
|
SN74LVC2G32DCUR-P
PROTOTYPE
|
74LVC | Bulk | Active | OR Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74AHC1G08DBV3
IC GATE AND 1CH 2-INP SOT23-5
|
74AHC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SNJ54ALS02J
NOR GATE, ALS SERIES
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
|
SN74LVC1G08DCKR-P
PROTOTYPE
|
74LVC | Bulk | Active | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
