| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
DM74S08J
AND GATE, TTL
|
74S | Bulk | Active | AND Gate | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SN74S86NSR
IC GATE XOR 4CH 2-INP 14SOP
|
74S | Tape & Reel (TR) | Obsolete | XOR (Exclusive OR) | 2 | - | 4.75V ~ 5.25V | 1mA, 20mA | 0.8V | 2V |
|
SNJ54HC04W
MILITARY 6-CH, 2-V TO 6-V INVERT
|
54HC | Tube | Active | Inverter | 6 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LS09DR
IC GATE AND OPEN 4CH 2-IN 14SOIC
|
74LS | Tape & Reel (TR) | Active | AND Gate | 2 | Open Collector | 4.75V ~ 5.25V | -, 8mA | 0.8V | 2V |
|
|
SN74AHC1G14DCKR-P
PROTOTYPE
|
74AHC | Bulk | Active | Inverter | 1 | Schmitt Trigger | 2V ~ 5.5V | 8mA, 8mA | 1.9V ~ 3.35V | 2.2V ~ 3.85V |
|
SN74AHC1G86DBVT
IC GATE XOR 1CH 2-INP SOT23-5
|
74AHC | Tape & Reel (TR) | Discontinued at | XOR (Exclusive OR) | 2 | Schmitt Trigger Input | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74LS00N
IC GATE NAND 4CH 2-INP 14DIP
|
74LS | Tube | Active | NAND Gate | 2 | - | 4.75V ~ 5.25V | 400µA, 8mA | 0.8V | 2V |
|
SN74AHC32MDREP
IC GATE OR 4CH 2-INP 14SOIC
|
74AHC | Tape & Reel (TR) | Active | OR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
|
SN74AHC02BQAR
IC GATE NOR 4CH 2-INP 14WQFN
|
74AHC | Tape & Reel (TR) | Active | NOR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
SN74AHC1G02DCKT
IC GATE NOR 1CH 2-INP SC70-5
|
74AHC | Tape & Reel (TR) | Discontinued at | NOR Gate | 2 | - | 2V ~ 5.5V | 8mA, 8mA | 0.5V ~ 1.65V | 1.5V ~ 3.85V |
|
74AHC1GU04DBVRG4
IC INVERTER 1CH 1-INP SOT23-5
|
74AHC | Tape & Reel (TR) | Discontinued at | Inverter | 1 | - | 2V ~ 5.5V | 8mA, 8mA | 0.3V ~ 1.1V | 1.7V ~ 4.4V |
|
|
SN74AHCT1G14DCKR-P
PROTOTYPE
|
74AHC | Bulk | Active | Inverter | 1 | Schmitt Trigger | 4.5V ~ 5.5V | 8mA, 8mA | 1.5V ~ 1.6V | 2V |
