| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
JM38510/30001BDA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54LS | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74AC14BQAR
6-CH, 2-V TO 6-V INVERTERS WITH
|
74AC | Tape & Reel (TR) | Active | Inverter | 6 | Schmitt Trigger | 2V ~ 6V | 24mA, 24mA | 1V ~ 2.3V | 2.2V ~ 3.9V |
|
|
JM38510/30007BDA
MILITARY 2-CH, 4-INPUT, 4.5-V TO
|
54LS | Tube | Active | NAND Gate | 4 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
74AC11032DBR
IC GATE OR 4CH 2-INP 16SSOP
|
74AC | Tape & Reel (TR) | Active | OR Gate | 2 | - | 3V ~ 5.5V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
SNJ54LS27J
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54LS | Tube | Active | NOR Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
M38510/30001BCA
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54LS | Tube | Active | NAND Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.8V | 2V |
|
SN74AC86DE4
IC GATE XOR 4CH 2-INP 14SOIC
|
74AC | Bulk | Active | XOR (Exclusive OR) | 2 | - | 2V ~ 6V | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V |
|
|
M38510/30005B2A
MILITARY 3-CH, 3-INPUT, 4.5-V TO
|
54LS | Tube | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
|
SNJ54LS266W
MILITARY 4-CH, 2-INPUT, 4.5-V TO
|
54LS | Tube | Active | XNOR (Exclusive NOR) | 2 | Open Collector | 4.5V ~ 5.5V | 4mA | 0.7V | 2V |
|
SN54HC36J
NOR GATE, CMOS
|
* | Bulk | Active | - | - | - | - | - | - | - |
|
54LS02LMQB
NOR GATE, LS SERIES TTL
|
54LS | Bulk | Active | NOR Gate | 2 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
|
54LS10DMQB
NAND GATE, LS SERIES TTL
|
54LS | Bulk | Active | NAND Gate | 3 | - | 4.5V ~ 5.5V | 400µA, 4mA | 0.7V | 2V |
