| Image | Mfr Part # | Series | Package | Product Status | Logic Type | Number of Inputs | Features | Voltage - Supply | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LVC2G14DCKR
IC INVERT SCHMITT 2CH 2IN SC70-6
|
74LVC | Tape & Reel (TR) | Active | Inverter | 2 | Schmitt Trigger | 1.65V ~ 5.5V | 32mA, 32mA | 0.3V ~ 1.4V | 1.4V ~ 3.7V |
|
SN74LVC1GU04DRY2
IC INVERTER 1CH 1-INP 6SON
|
74LVC | Tape & Reel (TR) | Active | Inverter | 1 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.41V ~ 1.38V | 1.24V ~ 4.13V |
|
SN74HC27D
IC GATE NOR 3CH 3-INP 14SOIC
|
74HC | Tube | Discontinued at | NOR Gate | 3 | - | 2V ~ 6V | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V |
|
SN74LVC1G38DBVR
IC GATE NAND OD 1CH 2-IN SOT23-5
|
74LVC | Tape & Reel (TR) | Active | NAND Gate | 2 | Open Drain | 1.65V ~ 5.5V | -, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74LVC2GU04YZPR
IC INVERTER 2CH 2-INP 6DSBGA
|
74LVC | Tape & Reel (TR) | Active | Inverter | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.41V ~ 1.38V | 1.24V ~ 4.13V |
|
SN74LVC00AMPWREP
IC GATE NAND 4CH 2-INP 14TSSOP
|
74LVC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 2V ~ 3.6V | 24mA, 24mA | 0.8V | 2V |
|
SN74HC14NS
IC INVERT SCHMITT 6CH 1-INP 14SO
|
74HC | Tube | Discontinued at | Inverter | 1 | Schmitt Trigger | 2V ~ 6V | 5.2mA, 5.2mA | 0.1V ~ 0.26V | 1.998V ~ 5.8V |
|
|
SN74AHCT08NSR
IC GATE AND 4CH 2-INP 14SOP
|
74AHCT | Tape & Reel (TR) | Active | AND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
|
|
SN74LVC86ADR
IC GATE XOR 4CH 2-INP 14SOIC
|
74LVC | Tape & Reel (TR) | Active | XOR (Exclusive OR) | 2 | - | 1.65V ~ 3.6V | 24mA, 24mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
SN74LVC2G00DCUT
IC GATE NAND 2CH 2-INP 8VSSOP
|
74LVC | Tape & Reel (TR) | Active | NAND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.58V ~ 1.65V | 1.07V ~ 3.85V |
|
SN74LVC2G08DCUT
IC GATE AND 2CH 2-INP 8VSSOP
|
74LVC | Tape & Reel (TR) | Active | AND Gate | 2 | - | 1.65V ~ 5.5V | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V |
|
74AHCT1G00DCKRG4
IC GATE NAND 1CH 2-INP SC70-5
|
74AHCT | Tape & Reel (TR) | Discontinued at | NAND Gate | 2 | - | 4.5V ~ 5.5V | 8mA, 8mA | 0.8V | 2V |
